LIGHTWEIGHT TELEHANDLERS
Telehandler HTL 3614
| Maximum lift capacity | 3600 kg |
| Lift capacity to full height | 3000 kg |
| Lift capacity at full reach | 800 kg |
| Maximum fork height | 13.60 m |
| Reach at maximum fork height | 1.50 m |
| Maximum forward reach | 9.80 m |
| Overall length | 6.43 m |
| Overall width – stabilizers down | 3.34 m |
| Transport width | 2.43 m |
| Transport height | 2.60 m |
| Ground clearance | 50 cm |
| Track width | 2.00 m |
| Wheelbase | 2.89 m |
| Approach angle | 29 |
| Turning radius – outside wheels | 4.50 m |
| Upper rotation of forks | 18 |
| Lower rotation of forks | 104 |
| Cabin width | 0.96 |
| 4 x 4 tires | 400/70-20 |
| Diesel engine | TIER IV 3400 cmc |
| Engine power | 55.4 kW / 2200 rpm |
| Engine torque | 375 Nm / 1400 rpm |
| Weight | 10340 kg |
